OEC Dry-Shield® WRB505WH, Round Gang Weatherproof Box, (5) 1/2 in Outlets, 1.40 in Deep, Die-Cast Aluminum, 16 Cu.in, White

Features

  • Durable die-cast aluminum construction provides a long product life.
  • Precision cast and machined surfaces allow safer wire-pulling.
  • Mounting lugs for a variety of mounting methods.
  • Available in gray, black, bronze and white.

Available on backorder

Catalog
Compare
Category:
General Specification
Product Description Round Gang Weatherproof Box, (5) 1/2 in Outlets, 1.40 in Deep, Die-Cast Aluminum, 16 Cu.in, White
Catalog ID WRB505WH
UPC 840449608999
Application Wet Locations
Brand OEC
Inner Box Quantity
Master Box Quantity
Product Specification
Standard Material Die Cast Aluminum
Standard Finish Powder Coated
Color White
Number of Gangs 2 Gang
Outlets Holes 5-1/2 in
Capacity 16 Cu.in
Dimensions
Product Height 5.50 in
Product Width 4.50 in
Product Depth 1.40 in
Certifications and Compliance
cULus Yes
Standard NEMA 3R
RoHS Yes
