99065A
Back to products
98201

B002

OEC B002, Copper Mechanical Splice, Conductor Range 4-14

Features

  • Manufactured from high strength aluminum alloy
  • Chamfered entry
  • Electro-Tin plated for corrosion resistance
  • UL486A/B Listed for Wire Connectors
  • Suitable for use with either copper or aluminum conductors
  • Provides low contact resistance
  • Provides ease of installation

Available on backorder

Compare
Categories: ,
General Specification
Product Description Copper Mechanical Splice, Conductor Range 4-14
Catalog ID B002
UPC
Application Terminating Connector
Brand OEC
Inner Box Quantity
Master Box Quantity
Product Specification
Connector Type Mechanical
Conductor Type Stranded
Standard Material Copper
Number of Poles 1
Number of Conductor 2
Screw Type Slotted
Dimensions
Product Length 0.90 in
Product Width 0.37 in
Product Height 2.25 in
Electrical Ratings
Voltage – Maximum 35000
Voltage Rating 35 kV
Temperature Rating
Temperature Rating 90°C
Conductor Related
Conductor Size 10 – 14 AWG
CU Conductor Str Range 14 AWG, 12 AWG, 10 AWG
Certifications and Compliance
cULus Yes
CSA Yes
RoHS Yes
