OEC 99901C, Copper, Mechanical Lug, I-Beam Style, Conductor Range 6 – 14, 1 Port, 1 Hole, 1/4 in Stud
Available on backorder
| Product Description | Copper, Mechanical Lug, I-Beam Style, Conductor Range 6 – 14, 1 Port, 1 Hole, 1/4 in Stud |
| Catalog ID | 99901C |
| UPC | |
| Application | Terminating Connector |
| Brand | OEC |
| Inner Box Quantity | |
| Master Box Quantity |
| Connector Type | Mechanical |
| Conductor Type | Copper |
| Standard Material | Copper |
| Standard Finish | Natural |
| Number of Holes | 1 |
| Number of Conductor | 1 |
| Screw Type | Allen Hex |
| Torque | 35 in-lbs |
| Product Length | 1.06 in |
| Product Width | 0.50 in |
| Product Height | 0.49 in |
| Stud Size | 1/4 in |
| Stud Hole | 0.27 in |
| Voltage – Maximum | 35000 |
| Voltage Rating | 35 kV |
| Temperature Rating | 90°C |
| Conductor Size | 6 – 14 AWG |
| CU Conductor Sol/Str Range | 6 AWG, 8 AWG, 10 AWG, 12 AWG |
| CU Conductor Sol/Str Size | 6 – 14 AWG |
| cULus | Yes |
| CSA | Yes |
| RoHS | Yes |
