98553D
Back to products
98554B

96157

OEC 96157, 240 mm2, Copper, One Hole, Long Barrel Metric Compression Lug, Compact Class B, C, Flex Class G, H, I, K, M & DLO, Color Coded, Cu Only

Features

  • Made of high conductivity copper tubing
  • Tinned for corrosion resistance
  • With inspection hole to ensure appropriate conductor insertion

Available on backorder

Compare
Category:
General Specification
Product Description 240 mm2, Copper, One Hole, Long Barrel Metric Compression Lug, Color Coded, Die Index
Catalog ID 96157
UPC
Application Wire Termination
Brand OEC
Inner Box Quantity
Master Box Quantity
Product Specification
Connector Type Copper
Conductor Material Copper Only
Standard Material Copper
Standard Finish Electro Tin plated
Tang Type Long
Barrel Type Long
No of Holes 1
Dimensions
Product Length 97.00 in
Barrel Length 43.00 in
Tang width 38.00 in
Stud Size M14
Hole Spacing 0.31 in
Electrical Ratings
Voltage – Maximum 35000
Voltage Rating 35 kV
Temperature Rating
Temperature Rating 90°C
Conductor Related
CU Size 240 mm2
