OEC 61101HD, Aluminum, Splicer/Reducer, Conductor Range 2 – 14, 2 Screw, Tin Plated, AL9CU
Available on backorder
| Product Description | Aluminum, Splicer/Reducer, Conductor Range 2 – 14, 2 Screw |
| Catalog ID | 61101HD |
| UPC | |
| Application | Splicer/Reducer |
| Brand | OEC |
| Inner Box Quantity | |
| Master Box Quantity |
| Connector Type | Mechanical |
| Conductor Type | Aluminium / Copper |
| Standard Material | Aluminum |
| Standard Finish | Electro Tin Plated |
| Screw Type | Slotted |
| Product Length | 1.38 in |
| Product Width | 0.50 in |
| Product Height | 0.56 in |
| No of Screw | 2 |
| Voltage – Maximum | 35000 |
| Voltage Rating | 35 kV |
| Temperature Rating | 90°C |
| Conductor Size | 2 – 14 AWG |
| AL Conductor Str Range | 12 AWG, 10 AWG, 8 AWG, 6 AWG, 4 AWG, 2 AWG |
| AL Conductor Str Size | 12 – 2 AWG |
| CU Conductor Sol/Str Range | 14 AWG, 12 AWG, 10 AWG, 8 AWG, 6 AWG, 4 AWG, 2 AWG |
| CU Conductor Sol/Str Size | 2 – 14 AWG |
| cULus | Yes |
| Standard | 486A/B |
| CSA | Yes |
| RoHS | Yes |
