OEC Orion® 61004C, UV Rated Clear Multi-Tap Insulated Connector, Conductor Range 750 – 2, 2 Ports, Insulated Inline Splice, Pre-Filled Oxide Inhibitor with Closure Plugs, Dual Rated, AL9CU

Features

  • Insulated with high dielectric access plastisol
  • Dual rated for copper and aluminum conductors
  • UL486 A/B Listed for Wire Connectors
  • Cold temperature rated up to -45°C
  • Pre-filled with oxide inhibitor prevents oxidation moisture and contaminants from entering area
  • Supplied with removable access plugs
  • Black insulation is UV resistant
  • Insulation UV stabilized & listed to UL94 with V0 flammability

Available on backorder

CatalogSales Drawing
Compare
Category:
General Specification
Product Description #750 – 2, Clear Multi-Tap Connector, Inline Splice Double Stud , 2 Ports
Catalog ID 61004C
UPC 840449605790
Application Connecting Tap
Brand OEC
Inner Box Quantity
Master Box Quantity
Product Specification
Connector Type Insulated Multi-Tap
Standard Material Aluminum
Insulation Type Plastisol
Cable Entry Insulated Inline Splice
Number of Ports 2
Key 5/16 in Hex
Max Torque 310 in-lbs
Dimensions
Product Length 6.50 in
Product Width 2.75 in
Product Height 2.64 in
Screw Size 1 in
Electrical Ratings
Voltage – Maximum 600 V
Temperature Rating
Temperature Rating -45°C to 90°C
Conductor Related
AL/CU Conductor Size 500 Kcmil – 6 AWG
AL Conductor Range Str (Primary, Run, Main, Line) 500 Kcmil – 6 AWG
CU Conductor Range Str (Primary, Run, Main, Line) 500 Kcmil – 6 AWG
Flex Conductor Range 350 Kcmil
DLO Conductor Range 262.6 Kcmil
Certifications and Compliance
cULus Yes
Standard 486A/B
NEC 230.46
RoHS Yes
